Welcome post support importer,stockist, distributor, wholesaler to contact us. Inquiry with drawings are welcomed.
Adjustable Post Anchor
Adjustable post anchor, is kind of post support, which can not only secure post, but can well suit to post dimension and space. It’s made of fine carbon steel, and protected with hot dip galvanization or zinc to keep from decay and moisture. According to drawing, we can produce a series of competitive DIY adjustable pole anchors.
Height, width are variable. Range per client requirement.
Surface treatment: hot dip galvanized, zinc plating.
| Item | Dimension | Anchor height | Headroom | Thickness (top / base) |
Surface |
| Bracket | 80 – 160 | 245 – 315 | 120 – 190 | 4/5 | HDG |
| Anchor | 80*100 | 235 – 305 | 120 – 190 | 6/5 | HDG |
Adjustable Post Support
| Thickness ….. | Height….. | Bolt Sizes…. |
| 4mm | 75mm | Base: M12 |
| Stem: M12 | ||
| Base: M12 | ||
| 4mm | 160mm | Base: M12 |
| Stem: M12 | ||
| Base: M12 |
Bolt Down Post Holder
| Rod(mm) | Lower plate(mm) | Thickness(mm) | Surface |
| M24*200 | 110*110 | 4 | Zinc |
| M24*250 | 110*110 | 4 | Zinc |
| M24*330 | 110*110 | 4 | Zinc |
| M27*250 | 160*160 | 6 | Zinc |
| M16*100 | 80*80 | 4 | Zinc |
| M16*160 | 80*80 | 4 | Zinc |
| M20*200 | 110*110 | 4 | Zinc |
Bolt Down Post Support
| Thickness | Stirrup Size | Side Bolt Holes | Base Bolt Holes |
| 4.0mm | 100mm | 2 x M10 – 10mm Diameter | 2 x M12 Bolt Holes – 12mm Diameter |
| 4.0mm | 125mm | 2 x M12 – 12mm Diameter |
Cyclonic Post Support
| Thickness | Height | Stirrup Size | Bolt Size | Bolt holes |
| 5.0mm | 300mm | 90mm | Saddle: M12 | 14mm |
| 5.0mm | 300mm | 100mm | Saddle: M12 | 14mm |
| 5.0mm | 450mm | 90mm | Saddle: M12 | 14mm |
| 5.0mm | 450mm | 100mm | Saddle: M12 | 14mm |
| 5.0mm | 450mm | 115mm | Saddle: M12 | 14mm |
| 5.0mm | 450mm | 125mm | Saddle: M12 | 14mm |
| 5.0mm | 600mm | 90mm | Saddle: M12 | 14mm |
| 5.0mm | 600mm | 100mm | Saddle: M12 | 14mm |
| 5.0mm | 600mm | 115mm | Saddle: M12 | 14mm |
| 5.0mm | 600mm | 125mm | Saddle: M12 | 14mm |
| 5.0mm | 600mm | 140mm | Saddle: M12 | 14mm |
| 5.0mm | 600mm | 150mm | Saddle: M12 | 14mm |
Fence Post Support
Fence post support, also named as half stirrup post anchor, stirrup post anchor. Fence post support is made of rebar and steel plate with holes in order to stabilize timber posts. Galvanised post stirrups support protect wood post from corrosion.
It is ideal to be used where the post is placed against a wall, it can be fixed either from one side or secure wood post in between . Holes on the plate, rebar size can be customized.
It’s either be hot dip galvanized or zinc plated.
| Dimension | Height | Pin | Thickness | Surface |
| 60*60 | 100 | 18 * 200 | 4 | HDG |
| 70*60 | 100 | 18 * 200 | 4 | HDG |
| 80*60 | 100 | 18 * 200 | 4 | HDG |
| 90*60 | 100 | 18 * 200 | 4 | HDG |
| 100*60 | 100 | 18 * 200 | 4 | HDG |
| 120*60 | 100 | 18 * 200 | 4 | HDG |
| 140*60 | 100 | 18 * 200 | 4 | HDG |
Fencing Anchors
| Dimension | Anchor height | Headroom | Thickness (top / base) |
Surface |
| 80 – 160 | 245 – 315 | 120 – 190 | 6/5 | Zinc |
Galvanised Post Brackets
| Item | Dimension | Height | Thickness | Surface |
| Galvanised Post Brackets | 70*60 | 150 | 5 | HDG |
| 80*60 | 150 | 5 | HDG | |
| 90*60 | 150 | 5 | HDG | |
| 100*60 | 150 | 5 | HDG | |
| 120*60 | 150 | 5 | HDG | |
| Deck Post Brackets | 60*60 | 125 | 4 | HDG |
| 80*80 | 125 | 4 | HDG | |
| 100*100 | 125 | 4 | HDG | |
| 120*120 | 125 | 4 | HDG | |
| 140*120 | 125 | 4 | HDG |
Garden Post Supports
| Dimension | Pin diameter | Thickness | Surface |
| 60*60 | 16 | 4 | HDG |
| 80*80 | 16 | 4 | HDG |
| 100*100 | 16 | 4 | HDG |
| 120*120 | 20 | 4 | HDG |
| 140*120 | 20 | 4 | HDG |
H Temporary Fence Post Anchors
H Temporary Fence Post Anchors hold the post between two steel columns at one end and the other end isset into concrete or ground. It is made of fine steel base, and is hot-dip galvanized to protect the post support from decay. Size and shape of the post support can be customized.
Application: It is widely used for carports, fences, play sets, pergolas, arbor and balconies, etc.
| Dimension | Strip width | Height | Surface |
| 80 | 60 | 600 | HDG |
| 100 | 60 | 600 | HDG |
| 120 | 60 | 600 | HDG |
Heavy Duty Post Supports
| Dimension | Pin diameter | Thickness | Surface |
| 80*60 | 18×200 | 4 | HDG |
| 100*60 | 18×200 | 4 | HDG |
| 120*60 | 18×200 | 4 | HDG |
Pole Supports
| Dimensions (mm) | Pin diameter (mm) | Surface |
| 70*70 | 20 | HDG |
| 90*90 | 20 | HDG |
Post Spike
Do you want quick fence installation ? Do you want last long fence foundation ? To set fence for garden, farm, mailbox post, pergola, metal fence post spike is a great choice.
It allows easy installation without digging holes or pouring concrete. It’s manufactured from sturdy steel. Two protective coatings post stake is designed to last for years: hot dip galvanized and powder coating.There are round posts ground spike and square posts ground spike available.
Post spike is a metal spike with sharp end buried underground as base and square/round end to hold poles above ground level to protect the wood post from delay, insect and corrosion.
The usage of metal anchor spike holders substitute the cement mounding, who has high costs, high labor intensity, high pollution with long time construction. With application of the metal spike holders, it become great to install posts into hard or soft soil, concrete, decking, slab etc.
| Dimension | Length | Thickness | Surface |
| 50*50 | 600 | 2 | HDG |
| 70*70 | 750 | 2 | HDG |
| 90*90 | 750 | 2 | HDG |
| 100*100 | 900 | 2 | HDG |
| 120*120 | 900 | 2 | HDG |
Post Support Bracket
| Dimensions(mm) | Pin diameter(mm) | Section thickness(mm) | Surface |
| 60*60 | 16 | 4 | HDG |
| 80*80 | 16 | 4 | HDG |
| 100*100 | 16 | 4 | HDG |
| 120*120 | 20 | 4 | HDG |
| 140*120 | 20 | 4 | HDG |
Post Supports Pergola
| Dimension | Base | Thickness | Surface |
| 60*60 | 110*110 | 4 | HDG |
| 80*80 | 110*110 | 4 | HDG |
| 100*100 | 110*110 | 4 | HDG |
| 120*120 | 110*110 | 4 | HDG |
| 140*120 | 110*110 | 4 | HDG |
Steel Post Base
Post base is ideal to be used for timber frames and post and beam building, especially when install posts into concrete or hard surface areas. It is suitable to be used on fence posts, pergolas, decks, canopy etc. The fence post base is manufactured from mild steel coated or in galvanized to protect against surface rust. According to shape of wood post, it includes round bolt down post base, square bolt down post anchor.
| Item | Dimension | Height | Thickness(base / side) | Surface |
| Square | 70*70 | 150 | 4/3 | HDG |
| 90*90 | 150 | 4/3 | HDG | |
| 100*100 | 150 | 4/3 | HDG | |
| 120*120 | 170 | 4/3 | HDG | |
| Round | 80 | 150 | 4/3 | HDG |
| 100 | 150 | 4/3 | HDG |
T Blade Post Support
| Blade Height (mm) |
Base Size (mm) |
Steel Thickness (mm) |
Suits Post Size (mm) |
Bolt Sizes |
| 250 | 80 x 80 | 10 | 90 – 100 | Base: M12 |
| Blade: M12 | ||||
| 275 | 110 x 110 | 10 | 115 – 140 | Base: M16 |
| Blade: M16 | ||||
| 300 | 140 x 140 | 10 | 150 – 180 | Base: M16 |
| Blade: M16 | ||||
| 350 | 180 x 180 | 10 | 180 – 250 | Base: M16 |
| Blade: M16 |
T Blade Post Support Cap
| Size | Cap Height | To Suit Base Size | Suits Post Size |
| 90 x 90 | 30 | 80 x 80 | 90 – 100 (mm) |
| 120 x 120 | 30 | 110 x 110 | 115 – 140 (mm) |
| 150 x 150 | 30 | 140 x 140 | 150 – 180 (mm) |
| 190 x 190 | 30 | 180 x 180 | 180 – 250 (mm) |
Timber Post Brackets
| Dimension | Base | Thickness | Surface |
| 60*60 | 150*60 | 4 | HDG |
| 80*80 | 150*60 | 4 | HDG |
| 100*100 | 150*60 | 4 | HDG |
| 120*120 | 150*60 | 4 | HDG |
| 140*120 | 150*60 | 4 | HDG |
Wooden Post Holder
Wooden post holder to secure wood post in between.
| Dimension | Base | Thickness | Surface |
| 80/200/60 | 170 | 5 | HDG |
| 90/200/60 | 180 | 5 | HDG |
| 100/200/60 | 190 | 5 | HDG |
| 120/200/60 | 210 | 5 | HDG |
Fence Post Support
Fence post supports are crucial for maintaining the stability and durability of your fence. They serve as the foundation of the fence, providing the necessary structural integrity to keep it standing strong. Without such support, a fence is susceptible to leaning, shifting, or even collapsing, which compromises its functionality and aesthetic appeal.
| A | B | Thickness | Surface |
| 100 | 200 | 6 | yellow galvanized, zinc |
| 120 | 250 | 8 | yellow galvanized, zinc |
| 140 | 250 | 8 | hot galvanized, zinc |
Screw in Post Support
Screw-in fence post supports are a practical choice, especially for smaller fences or temporary installations. They have a spiral shape that can be twisted directly into the ground. This type of support is relatively quick to install and can be easily removed or repositioned when needed.
| A | B | Thickness | Surface |
| 60 | 550 | 1.7 | hot galvanized, zinc |
| 68 | 650 | 1,8 | hot galvanized, zinc |
| 68 | 800 | 1.8 | hot galvanized, zinc |
Screw in Post Support with Bar
Screw-in fence post supports provide a convenient and efficient solution for installing sturdy fences. With their easy installation process, versatility, and adjustability, these supports offer numerous benefits for both DIY enthusiasts and professional fence builders.
| A | B | Thickness | Surface |
| 60 | 550 | 1.7 | hot galvanized, zinc |
| 68 | 550 | 1,8 | hot galvanized, zinc |
Ground Anchor Screw
Anchor screws are designed to provide excellent strength and stability to fence posts. They are built to withstand various weather conditions and the test of time.
| A | B | Thickness | Surface |
| 70 | 685 | 1.8 | hot galvanized, zinc |
| 80 | 685 | 1,8 | hot galvanized, zinc |
| 90 | 685 | 1,8 | hot galvanized, zinc |
| 100 | 865 | 1,8 | hot galvanized, zinc |
| 120 | 865 | 1,8 | hot galvanized, zinc |
